RK-756 Hydraulic Riveting Tool for Collar Bolts and Structural Rivets (Tool Only)
RK-756 Hydraulic Riveting Tool for Collar Bolts and Structural Rivets (Tool Only)
Introducing the Rivet King RK-756 Hydraulic installation tool. For installation of CollarBolts® , In-Locks® and TigerBolts® up to 3/8″ in Diameter. Weights 11.1 lbs (5.03 kg). Setting Stroke 0.96″ (24.38mm). Pull Load rated at 10,000 lbs (44.48 Kn). Requires clean, dry compressed air, regulated at 90 to 100 psi (6.2-6.9 bar). ***Tool Only*** Nose Assemblies to be specified separately per fastener requirment. Industry standard nose assemblies from Huck and Gagebilt are compatible.
- Models
- Video
- Product Assistance
- Features/Benefits
- Accessory
- Download
| Model# | Capacity* | Max Force | Stroke |
| RK-756 | 3/16″ to 3/8″ diameter CollarBolts, In-Lock and TigerBolts | 10,000lbs. | 0.96″ |
*Tool capacity is subject to max force value.
Video in development. Check back soon!
Industrial Rivet & Fastener Co. can help you select the right product or tool for your application. Please contact our experienced Product Specialists with any questions. We look forward to hearing from you! 1-800-BUY-RIVET or info@rivet.com
Tool Body:
- Weight: 11.1 lbs (5.03 kg)
- Tool Stroke: 0.96” (24.38mm)
- Pull Force: 10,000 lbs.
Nose Assemblies for Blind Rivets and Lock/Collar Bolts. Compatible with industry standard nose assemblies from Huck and Gagebilt.
Product manual in development. Check back soon!
